Chipset Atheros, 6th Generation, AR5414 with SuperA/Turbo Support
Operation Voltage 3.3VDC
Antenna Ports Single MMCX
Temperature Range -45 to +85C (extended temp version up to +95C)
Security WPA, WPA2, AES-CCM & TKIP Encryption, 802.1x, 64/128/152bit WEP
XR3-3.5 XR3-3.7
Data Rates 6Mbps, 9Mbps, 12Mbps, 24Mbps, 36Mbps, 48Mbps. 54Mbps
RoHS Compliance YES
TX Channel Width Support 5MHz / 10MHz / 20MHz / 40MHz
FREQUENCY RANGE (VERSION DEPENDENT)
2.70GHz-2.90GHz 3.400-3.7GHz* 3.65-3.70GHz (FCC Part90Y)
XR3-2.8
Up to 150meters
RANGE PERFORMANCE
RADIO PERFORMANCE
TX SPECIFICATIONS RX SPECIFICATIONS
5MHz 10MHz 20MHz
802.11a OFDM
Operating System Support Linux MADWIFI, WindowsXP, Windows2000
802.11a OFDM
802.11a OFDM
ADJUSTABLE CHANNEL SIZE SUPPORT (Increase Channel Capacity or Increase Throughput)
CURRENT CONSUMPTION INFORMATION
Over 50km
40MHz (Turbo)
TX CURRENT CONSUMPTION RX CURRENT CONSUMPTION
802.11a OFDM
