Descrição Curta
Tipo de Rede: Wireless Ethernet - 108 Mbps IEEE802.11g,
Wireless Ethernet - 11 Mbps IEEE802.11b,
Wireless Ethernet - 54 Mbps IEEE802.11g
Tipo de Dispositivo: Router
Wireless Device
Network Status Indicators: Activity Status,
Link Status,
Power,
Wireless
Number of Antennas: 1
Device Type: Router
Networking Standards
Características: Integrated Firewall,
IPSec,
NAT
Wireless Security Features: PSK,
WEP - 128-bit,
WEP - 64-bit,
WPA
Speeds Supported: 108 Mbps
Network Architecture Supported: Wireless Ethernet - 108 Mbps IEEE802.11g,
Wireless Ethernet - 11 Mbps IEEE802.11b,
Wireless Ethernet - 54 Mbps IEEE802.11g
Ports
Number of Ports: 4
Port Types: Ethernet - RJ-45,
SMA jack
Dimensões
Peso: 11.2 oz
Profundidade: 7.6 in
Largura: 4.6 in
Altura: 1.2 in


Technical Specifications
Standards • IEEE 802.11g
• IEEE 802.11b
• IEEE 802.3
• IEEE 802.3u

Wireless Signal Rates* With Automatic Fallback • 108, 54, 48, 36, 24, 18, 12, 11, 9, 6, 5.5, 2, & 1Mbps

Wireless Frequency Range • 2.4GHz to 2.462GHz

Wireless Transmit Power • 15dBm ± 2dBm

Receiver Sensitivity* • 54Mbps OFDM, 10% PER, -68dBm
• 48Mbps OFDM, 10% PER, -68dBm
• 36Mbps OFDM, 10% PER, -75dBm
• 24Mbps OFDM, 10% PER, -79dBm
• 18Mbps OFDM, 10% PER, -82dBm
• 12Mbps OFDM, 10% PER, -84dBm
• 11Mbps CCK, 8% PER, -82dBm
• 9Mbps OFDM, 10% PER, -87dBm
• 6Mbps OFDM, 10% PER, -88dBm
• 5.5Mbps CCK, 8% PER, -85dBm
• 2Mbps QPSK, 8% PER, -86dBm
• 1Mbps BPSK, 8% PER, -89dBm

External Antenna Type • Single Detachable Reverse SMA

Modulation Technology • Orthogonal Frequency Division Multiplexing (OFDM)
• Complementary Code Keying (CCK)

Security • 64/128-bit WEP
• Wi-Fi Protected Access (WPA-PSK, WPA-EAP)

Advanced Firewall Features • Network Address Translation (NAT) with VPN Pass-through
• Stateful Packet Inspection (SPI)
• MAC Filtering
• Website Filtering
• Scheduling

VPN Pass Through/Multi-Sessions • PPTP / L2TP / IPSec

Device Management • Internet Explorer v6 or later; or other Java-enabled Browsers
• DHCP Server and Client

Led • Power
• Status
• WAN
• WLAN (Wireless Connection)
• LAN (10/100)

Certifications • FCC

Operating Temperature • 32°F to 131°F (0°C to 55°C)

Operating Humidity • 90% Maximum (Non-condensing)

Dimensions • Item (WxDxH): 4.9” x 7.9” x 1.4”
• Packaging (WxDxH): 8.3” x 10.9” x 2.7”

Weight • Item: 0.7 lbs
• Packaging: 1.9 lbs

Warranty • 1 Year**

Minimum System Requirements • Cable or DSL Modem
• Computer with:• Windows® XP SP2 or Windows 2000 SP4*** or Mac OS® X (v10.4/v10.3)****
• Internet Explorer 6 or Mozilla Firefox
• CD-ROM Drive
• Network Interface Card


Package Contents • RangeBooster G Router
• Detachable Antenna
• CAT5 Ethernet Cable
• Power Adapter
• Mounting Kit and Vertical Stand
• CD-ROM***** with:• Installation Wizard
• Product Documentation
