CAPACIDADE DE ALCANCE 4 A 5KM
Electrical Specifications
Frequency 2400-2500 MHz
Gain 24 dBi
-3 dBi Beam Width 8 degrees
Cross Polarization Rejection 26 dBi
Front to Back Ratio 24 dB
Sidelobe -20dB Max
Impedance 50 Ohm
Max. Input Power 50 Watts
VSWR < 1.5:1 avg.

Mechanical Specifications
Weight 4.8 lbs. (2.18 kg)
Grid Dimensions 39.5 in (100 cm) x 23.5 in (60 cm)
Mounting 2 in. (50.8 mm) diameter mast max.
Elevation Angle 0 to +10 degrees
Operating Temperature -45° C to +85° C

Wind Loading Data
Wind Speed
(MPH) Loading
(2.1 sq. ft.)
40 16.4 lb.
60 36.3 lb.
80 63.8 lb.
100 97.0 lb.
120 147.0 lb.
140 199.5 lb.
