ESPECIFICAÇÕES
Processor
Socket 754 for AMD Athlon 64 / Sempron, K8 CPUs, support up to 800MHz FSB, DDR 400
Chipset
VIA K8M800 / 8237
Embedded UniChrome II 3D Graphics with 64M share memory
VIA VT6103 10/100Mbps Fast Ethernet PHY
ALC655 6-channel audio Codec
Compliant with AC"97 2.3 specification
System BIOS
AMI 4Mb Flash ROM
Supports Plug and Play 1.0A, APM 1.2, Multi Boot, DMI
Full support for ACPI revision 1.0 specification
Memory
2 x 184-pin DIMM sockets support two 2.5V DDR SDRAMs (DDR400/333/266)
Maximum: 2GB
Expansion Slots
1 x AGP 8X
2 x PCI
1 x CNR
Form Factor & Layers
Micro-ATX Form Factor, 244*190mm
