Electrical Specifications
Frequency
2400 - 2500 MHz

Gain
14 dBi

Polarization
Vertical

Horizontal Beam Width
120°

Vertical Beam Width
15°

Impedance
50 Ohm

VSWR
< 1.5:1 avg.

Front to Back Ratio
> 21 dB

Max. Input Power
300 Watts

Lightning Protection
DC Ground

Connector Integral N-Female

Mechanical Specifications
Weight
4.4 lbs. (2 kg)
Dimensions
20 x 7 x 3.5 inch
(500 x 180 x 90 mm)
Radome Material
UV-inhibited Plastic

Mounting
2 inch (50 mm) dia. mast max.
Operating Temperature -40° C to to 85° C
(-40° F to 185° F)
Rated Wind
>130 MPH (210 Km/h)
